BLLA 155 P 2433

BOSCH INJECTOR NOZZLE: DLLA155P2433 – FULL SPECIFICATION

I. Key Identification & Compatible Injectors

Nozzle (Injector Tip) P/N: DLLA155P2433
BOSCH MEC / Catalog Number: 433172433
System Manufacturer: BOSCH Common Rail Diesel Injection System.

Compatible Injector Assembly P/N(s):
- BOSCH Injector Reference: 0 445 110 618
- OEM / Vehicle Manufacturer: OPEL / Vauxhall – 1.3 CDTI engines, Corsa E, Combo Van, E Engine variants
- Typical Applications: Corsa E 1.3 CDTI, Combo Van 1.3 CDTI, other FCA / Opel small diesel vehicles using MultiJet II derivatives.

II. Vehicle / Engine Application & Technical Data

Primary Vehicle Application: Opel / Vauxhall 1.3 CDTI diesel engines in passenger cars and vans.
Engine Type: 1.3 L inline-4 MultiJet II / Euro 6 diesel engines, 70–95 HP variants.
Injector Technology: BOSCH Solenoid-Type Common Rail Injector.
Nozzle Type: DLLA155P2433 — high-precision multi-hole nozzle for optimal fuel atomization and emissions compliance.
Technical Characteristics:
- Number of Holes: 7–8
- Hole Diameter: approx. 0.130–0.140 mm
- Spray Angle: 155°
- Operating Pressure: 1600–1800 bar
- Emission Standard Compatibility: Euro 6 / Euro 5
- Material: Heat-treated, high-strength tool steel with anti-wear surface treatment
- Fuel Compatibility: EN 590 Diesel / B7 Biodiesel blends
- Performance Features: Optimized for low NOx, reduced noise, improved cold start, and fuel efficiency.

III. Critical Technician Notes (MUST-DO)

1. Injector Coding: After replacement, perform IMA/ISA coding using OEM or BOSCH diagnostic tools.
2. Sealing Components: Always install new copper washers and O-rings; old seals may cause compression leaks.
3. Injector Bolts: Replace all stretch bolts; torque-angle method required.
4. Clean Installation: Maintain absolute cleanliness; MultiJet injectors are sensitive to contamination.
5. System Verification: Conduct leak-back test, pilot injection calibration, rail pressure stability, and injector balance check.
6. Fuel System Notes: Replace fuel filter and check for water contamination; MultiJet systems are highly sensitive.
7. Seat Reconditioning: Clean injector seat of carbon deposits if present to prevent blow-by and misfire.
